Description
Product Overview
HY-21-DVTBXX 8in1/16in1/24in1 DVB-T modulator is an all-in-one device developed by DEXIN. It supports maximum 256 (or 512, or 768) IP input through the GE/SFP port and has 8 (or 16, or 24) multiplexing channels and 8 (or 16, or 24) DVB-T modulating channels of non-adjacent carriers (50MHz~960MHz). The device is characterized with high integrated level, high performance and low cost. This is very adaptable to newly generation DTV broadcasting system.
Key Features
- 3 GE ports for IP input and output –Version I & II
- 6 GE ports (4*RJ45, 2*SFP), data1-4 for IP input (RJ45/SFP), data 3-4 for IP output –Version III
- Max 840Mbps for each input
- Supports accurate PCR adjusting
- Supports PID remapping and PSI/SI editing
- Supports up to 180 PIDs remapping per channel
- Support 8 (or 16, or 24) multiplexed TS over UDP/RTP/RTSP output
- 8 (or 16, or 24) DVB-T non-adjacent carriers output, compliant to ETSI EN300 744 standard
- Supports RS (204,188) encoding
- Support Web-based Network managementProduct Overview
Inner Principle Chart
Version I & II – For 8&16 carriers out):
Version III – For 24 carriers out)::
Carrier Setting Illustration
Specifications
| Input | Input | Max 256/512 IP input through 3 (front-panel Data port, Data 1 and Data 2) 100/1000M Ethernet Port (SFP interface optional). – For Version I & II
Max 768 IP input through data ports 1 to 4 100/1000M Ethernet Ports (RJ45 and SFP interface alternative). –For Version III |
| Transport Protocol | TS over UDP/RTP, unicast and multicast, IGMP V2/V3 | |
| Transmission Rate | Max 840Mbps for each input channel | |
| Mux | Input Channel | 256 IP streams – Version I
512 IP streams – Version II 768 IP streams – Version III |
| Output Channel | 8 (or 16, or 24) | |
| Max PIDs | 180 per channel | |
| Functions | PID remapping(auto/manually optional) | |
| PCR accurate adjusting | ||
| PSI/SI table automatically generating | ||
| Modulation
Parameters |
Output Channel | 8 non-adjacent carriers output – Version I
16 non-adjacent carriers output – Version II 24 non-adjacent carriers output – Version III |
| Modulation Standard | ETSI EN300 744 | |
| Constellation | QPSK/16QAM/64QAM | |
| Bandwidth | 6/7/8 MHz | |
| Trans mode | 2K/4K/8K | |
| FEC | 1/2, 2/3, 3/4, 5/6, 7/8 | |
| RF Output | Interface | F typed output port for 8 (or 16) non-adjacent carriers |
| RF Range | 50~960MHz, 1kHz stepping | |
| Output Level | -20~+10dbm (for all carriers), 0.5db stepping | |
| MER | ≥ 40dB | |
| ACL | -55 dBc | |
| TS output | 8 (or 16, or 24) IP output over UDP/RTP/RTSP, unicast/multicast, 2 100/1000M Ethernet Ports | |
| System | Web-based Network management | |
| General | Demission | 420mm×440mm×44.5mm (WxLxH) |
| Temperature | 0~45℃(operation), -20~80℃(storage) | |
| Power Supply | AC 100V±10%, 50/60Hz or AC 220V±10%, 50/60Hz | |
Order Information:
| Type | Description | Version I | Version II | Version III |
| HY-21-DVBT8 | 256 IP input to 8ch DVB-T carriers out, 8 IP out | x | ||
| HY-21-DVBT16 | 512 IP input to 16ch DVB-T carriers out, 16 IP out | x | ||
| HY-21-DVBT24 | 768 IP input to 24ch DVB-T carriers out, 24 IP out | x |
Additional information
| Type | "DVBT08", "DVBT16", "DVBT24" |
|---|
