Description
Overview
1310Pxx series indoor 1310nm optical transmitter adopts famous brand high linearity DFB laser, and build-in perfect pre-distortion adjustment circuit. Owning the internal micro-processor auto monitor system, the transmitter would ensure excellent performance.
Main features
- High performance DFB laser.
- Excellent pre-distortion circuit to improve C/CTB and C/CSO
- AGC RF control circuit can ensure the constancy of laser’s modulation depth.
- ATC and APC can ensure the best operating status of laser.
- Slow start-up circuit and RF over-protection circuit ensure the laser will not be damaged.
- Perfect microprocessor automatic monitoring circuitry can monitor the operating status real-timely and precisely
- Front panel display status and alarm.
- With RJ-45 and RJ-232 interface, remote control conveniently.
Specification
| Item | Parameter |
| Optical | |
| Wavelength | 1310 ± 10 nm |
| Output power range | 2 ~ 30 mW (3 ~ 14 dBm) |
| Optical return loss | > 45 dB |
| RF | |
| Bandwidth | 47 ~ 862 MHz |
| RF input level | dBuV |
| Flatness, peak-to-valley | ± 0.75 dB |
| Impedance | 75 Ω |
| Input return loss | ≥ 16 (47 ~ 550)MHz; ≥ 14 (550 ~ 750/862)MHz |
| CNR | ≥ 51 dB |
| CTB | ≥ 65 dB |
| CSO | ≥ 60 dB |
| AGC\MGC range | ± 8 dB |
| User interface | |
| Optical connector | FC/APC or SC/APC |
| RF connector | F-“Female” connector |
| Power supply | AC 160 ~ 250V (50Hz) |
| HMI | VFD LCD display, 4*button |
| Online monitor | Ethernet & RS232 |
| Other characteristic | |
| Machine power consumption | Max 30 W |
| Operating temperature | 0ºC to + 45ºC |
| Storage temperature | -20ºC to + 65ºC |
| Relative humidity | 10% to 95% (no condensing) |
| Dimension | 483 × 380 × 44 mm |
Additional information
| 1310nm Power | 2mW, 4mW, 6mW, 8mW |
|---|---|
| Power Supply | Dual Power AC, Dual Power AC and DC, Dual Power DC 48V, Single Power AC, Single Power DC 48V |
