Mini 1550nm CATV+SATV Optical Transmitter SC/APC Fiber Port Single Power Out 10dBm 5km
Price range: $85.00 through $8,330.00
Each piece=USD85.00/pc
Description
Features:
- Designed for FTTH(Fiber To The Home) networks
- Wide operating frequency range:45~2400MHz
- Excellent Linearity and flatness
- Single-mode fiber high return loss
- Using GaAs amplifier active devices
- Ultra low noise technology
- Using DFB coaxial small package laser
- Smaller size and easier install
- Output 13/18V、0/22KHz for LNB working
- Using bicolor LEDs for 13/18V,0/22KHz output indication
- Using Aluminum alloy Housing, good heat dissipation performance
Specifications:
| Number | Item | Unit | Description | Remark |
| Customer Interface | ||||
| 1 | RF Connector | F-female | ||
| 2 | Optical Connector | SC/APC | ||
| 3 | Power Adapter | DC2.1 | ||
| Optical Parameter | ||||
| 4 | Optical Return Loss | dB | ≥45 | |
| 5 | Output Optical Wavelength | nm | 1550 | |
| 6 | Output Optical Power | mW | 10 | 10dBm |
| 7 | Optical Fiber Type | Single Mode | ||
| RF+SAT-IF Parameter | ||||
| 8 | Frequency Range | MHz | 45~860 | |
| 950~2400 | ||||
| 9 | Flatness | dB | ±1 | |
| 10 | Input Level | dBµV | 80±5 | RF |
| 75±10 | SAT-IF | |||
| 11 | Input Impedance | Ω | 75 | |
| 12 | Return Loss | dB | ≥12 | |
| 13 | C/N | dB | ≥52 | |
| 14 | CSO | dB | ≥65 | |
| 15 | CTB | dB | ≥62 | |
| 16 | LNB Power supply | V | 13/18 | |
| 17 | Maximum Current For LNB | mA | 350 | |
| 18 | 22KHz Accuracy | KHz | 22±4 | |
| Other Parameter | ||||
| 19 | Power Supply | VDC | 12 | |
| 20 | Power Consumption | W | <3 | |
| 21 | Dimensions | mm | 105x84x25 | |
Additional information
| Quantities | 1 pc, 2 pcs, 5 pcs, 10 pcs, 20 pcs, 50 pcs, 100 pcs |
|---|---|
| Connector | SC/APC-SC/APC, SC/APC-SC/UPC |
